Carbon steel plate ,Weather Resistant Steel Plate, ASTM A558 Corten Weather Resistant Steel Plate

ASTM A558 Corten Weather Resistant Steel Plate

Weather Resistant Steel Plate is a special type of steel plate with known as corten steel or weathering steel. COR-TEN has served as weathering steel (atmospheric corrosion- resistant steel). Corten steel plate has successfully overcome rust, steel’s most weakest. When exposed to the atmosphere without painting, corten steel begins to rust in the same way as ordinary steel. BUT soon the alloying elements in COR-TEN cause a protective surface layer of the fine-textured rust to form, thereby suppressing corrosion rate. Since its development in 1993, the COR-TEN has been used in every field where steel applied, such as bridges, railway vehicle and buildings. At present, COR-TEN are attracting attention as being suited for resources and environmental concerns as well as reducing life-cycle costs.

Product Details

Product Name	Weathering Resistant Steel Plate
Size	as required
Width	1600-4200mm or as required
Thickness	6mm-400mm
Standard	ASME/ASTM
Technique	Hot rolled
Surface Treatment	According to customer's requirement
Thickness Tolerance	±0.01mm~ ±0.25mm
Material	Corten A / B
Application	It is mainly used for railway, vehicle, bridge, tower and other steel structures exposed to the atmosphere for a long time.
MOQ	1 ton , We can accept sample order.
Shipment Time	Within 15-20 workdays after receiving deposit or workable L/C
Export Packing	Waterproof paper, and steel strip packed. Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Capacity	250,000 tons/year

Chemical Composition:

Grade	C	Si	Mn	Cr	Ni	Cu	Nb
Grade	≤%	%	%	%	%	%	%
Corten A	0.12	0.25-0.75	0.20-0.50	0.03	0.50-1.25	0.65	0.25-0.55
Corten B	0.19	0.25-0.80	0.30-0.65	0.40-0.65	0.40	0.25-0.40	/

Physical properties :

Grade	Permissible yield point	Yield Strength	Tensile Strength	Elongation	Bend
Grade	ratio	MPa(min)	MPa	% (min)	Bend
Corten A	/	355	470-630	20	1t
Corten B	/	345	485	19	/

Features of COR-TEN:

Weathering Resistance

Thanks to high weather resistance, corten steel can be used without painting. Unpainted applications are not only offer the economic advantage of reducing repainting costs; they also offer aesthetic benefits associated with the calming color of the protective rust.

Paint Durability

COR-TEN is pain-table in the same way as ordinary steel. In addition, even if a painting defect should occur, COR-TEN suppresses the progress of rust area and prolongs the services life of paint, thereby reducing repainting costs.

Weldability

While trace amounts of alloying elements such as copper (Cu) and chromate (Cr) are added to COR-TEN to ensure high weather resistance, the carbon content is lowered to provide appropriate weldability. Accordingly, COR-TEN can be welded using either manual, gas-shield or submerged arc welding.

Workability

COR-TEN possesses work-ability similar to ordinary steels of same strength.

Unpainted use of Cor-Ten

The unpainted application of corten steel not only offer economic advantages but also demonstrates excellent aesthetic properties. Because of this, COR-TEN is applied in a wide range of fields such as buildings and monuments. COR-TEN can be applied without painting-in a bare state, thus reducing the cost of repainting and other repairs. However, some of our clients have expressed their concerns during the first year or two then the protective lay of fine-textured rust is forming. In order to solve these concerns, supplementary rust stabilization treatment was developed.

Painted use of Cor-Ten

When COR-TEN is painted, the required number of times that repainting must be conducted can be reduced. This advantage is believed to result from the fact that, even when corrosion in the base metal due to defects in the panted film or to pinholes, the corrosion progresses slowly and thus the occurrence of blistering and peeling of the paint film is reduced. By making the most of this advantage. COR-TEN is applied in every field where steel is used-ranging from buildings to railway vehicle, marine containers, storage tanks, industrial machinery and bridges.

*
*
